RF CCT Wireless Wallplate | T22W
$87.89 Inc GST
6 in stock
LL-SD-T22W
Description
This RF CCT Wireless Wallplate features an ultra sensitive high strength glass touch panel with 4 zone control. The wallplate features both colour temperature adjustment and brightness control touch slider as well as on / off and customisable scene functions.
Being wireless allows the wallplate to be mounted virtually anywhere, providing unrivalled flexibility.
The wallplate can be used with any of the Skydance CCT receiver / controllers. Pairing is simply performed by: A short press of the match key on the receiver / controller. Followed by an immediate press of the on/off key on the remote. The LED indicator on the remote control will fast flash a few times, indicating the match is successful.
FEATURES:
- 4 Zone selection and control
- Colour temperature adjustment
- 256 levels of brightness
- Smooth dimming without flicker
- 30m range (with auto transmission)
- 1 remote can be paired to an infinite number of controllers/receivers
- Up to 10 remotes can be paired to just 1 controller/receiver
FUNCTIONS:
- On / Off
- Colour temperature adjustment
- Brightness control
Specifications
Function | CCT Control |
---|---|
Control Buttons | On / Off CCT adjustment Brightness adjustment |
Channels | 1 |
Zones | 4 |
Transmission Frequency | RF 2.4GHz |
Transmission Distance | 30m |
Batteries | 2x AA |
Operating Power Consumption | 5mA |
Standby Power Consumption | 20µa |
Standby Battery Lifetime | 1 Years |
Dimensions | 86 x 86 x 21mm |
IP Rating | IP20 |
Warranty | 5 Years |
Downloads
- LL-SD-T22 Instruction Manual (964 KB)
