This Mini CCT Remote Control has a simple button design allowing for easy, no fuss operation in a small package. The remote features six buttons offering on/off, brightness up & down, CCT (colour temperature) adjustment and off time delay functions. A small LED indicator lights up when a button is pressed and flashes when the selected function has reached its upper or lower limit.
Please note: This controller can work with any two colour LED strips such as white/red, not just CCT.
The remote can be used with any of the Skydance single colour receiver / controllers. Pairing is simply performed by: A short press of the match key on the receiver / controller. Followed by an immediate press of the on/off key on the remote. The LED indicator on the remote control will fast flash a few times, indicating the match is successful.
- Brightness adjustment: Short press 10 levels, long press 1-6s for continuous 256 levels adjustment
- Colour adjustment: Short press 11 levels, long press 1-6s for continuous 256 levels adjustment
- Smooth dimming without flicker
- 30m range (with auto transmission)
- 1 remote can be paired to an infinite number of controllers/receivers
- Up to 10 remotes can be paired to just 1 controller/receiver
- 6 Buttons
- On / Off
- Brightness +
- Brightness –
- Colour temperature +
- Colour temperature –
- Turn off 30sec / 60sec
|Function||Single colour dimmer|
|Control Buttons||6 Buttons
On / Off
10% Brightness (night light)
Turn off 30sec / 60sec
|Transmission Frequency||RF 2.4GHz|
|Operating Power Consumption||5mA|
|Standby Power Consumption||2µa|
|Standby Battery Lifetime||2 Years|
|Dimensions||100 x 47 x 8mm|
