This LED PIR motion switch will activate LED strip light when a body is detected within a 2m range. The light will remain on when a body is within the detection range. When a body leaves the detection range the sensor will switch off after 40 seconds. Eliminating the need for a traditional on/off wall switch or remote control.
The motion sensor is recess mount and only Ø14mm, meaning it can be mounted almost anywhere and virtually out of sight.
- On = Body <2m
- Off = Body >2m
|Input Voltage||12.0 ~ 24.0 VDC|
|Input Current||4 A|
|Output Voltage||12.0 ~ 24.0 VDC|
|Output Load||48W @ 12V / 96W @ 24V|
|Detection Range||<2 m|
|On Time Whilst Present||Always|
|On Time After Leaving||40 sec|
|Construction / Protection Data|
|Operating Temperature||-20 ~ +60 C°|
|Storage Temperature||-20 ~ +50 C°|
|Hole Size||Ø14 mm|
|Outside Diameter||Ø17 mm|
- LL-CON-PIR01 Data Sheet (1 MB)
